EQUIPMENT
-
Battery
7-5
BATTERY
N77ZDOOAA
i
The battery of the following specifications has been
established.
SPECIFICATIONS
Items
Specifications
Type
B.C.I. Group size 86
B.C.I. Group size 86
Capacity (5HR)
Ah
50
50
Reserve capacity
min.
90
90
Cold cranking current
A
430
525
345
347
