I-10
ENGINE <NON-TURBO>
-
Intake and Exhaust
INTAKE AND EXHAUST
INTAKE MANIFOLD AND EXHAUST MANIFOLD
tmAEooAA
i/i:
The intake manifold is a two-piece aluminum casting,
The exhaust manifold is made of nodular cast iron
attached to the cylinder head with six bolts and
for strength and high temperatures.
two studs. This long branch fan design enhances
low and
midspeed
torque.
I
EXHAUST PIPE
N71AEOlAA
The exhaust pipe consists of three parts: a front
transmission from the exhaust system to the body.
pipe, a center pipe, and a main muffler. It is mounted
A large main muffler, sub muffler and pre-muff ler
on the body via rubber hangers to minimize vibration
ensure reduced exhaust noise.
CONSTRUCTION
Flexible pipe
ted oxygen sensor
Pre-muff ler
Sub muffler
Heated oxygen sensor
Heated oxygen sensor
