WINDSHIELD WIPERS AND WASHERS
The windshield wiper comes in two types; two speed
e
The washer nozzle is a
2-nozzle,
4-jet
type.
type with fixed interval intermittent function, and
l
The windshield washer tank is installed in the
two speed type with variable intermittent function.
L.H. side of the engine compartment on
non-tur-
They have the following characteristics.
bo vehicles and in the R.H. side of the luggage
l
The wiper motor and links are mounted as a
compartment on turbo vehicles.
unit on a frame to enhance the serviceability.
l
A washer interlocked wiper function and mist
wiper function have been adopted for greater
convenience.
<Turbo>
Frame
Windshield
Wiper blade
Wiper arm
washer
I
I
tank
Nozzle
Link
Washer hose
<Non-turbo>
\Alinmr
hlzarin
WiPer
arm
Link
Al
6X0661
Frime
I
Nozzle
Winbshield
washer
tank
Washer
hose
