ENGINE
<TURBO>
-
Intake and Exhaust
I-67
INTAKE AND EXHAUST
i
i
INTAKE MANIFOLD AND EXHAUST MANIFOLD
N71
BEOOM
The intake and exhaust manifolds are basically the
same as the once currently used.
EXHAUST PIPE
The exhaust pipe consists of three parts: a front
pipe, a center pipe, and a main muffler with muffler
cutter. It is mounted on the body via rubber hangers
id
CONSTRUCTION
<FWD>
Pre-muffler
/
N71BEOlAA
to minimize vibration transmission from the exhaust
system to the body. A large main muffler, sub muffler
and pre-muffler reduce exhaust noise.
Muffler cutter
Sub muffler
\
/
Main muffler
Heated oxygen sensor
05x0090
F&t
pipe
<AWD>
Muffler cutter
/I
Flexible pipe
Center pipe
Front pipe
