INTERIOR - Seat
6-5
Power Seat Circuit
POWER SEAT SWITCH
I
FUSIBLE LINK @
POWER SEAT ASSEMBLI
SLIDE
FRONT HEIGHT REAR HEIGHT
I T
T T rl
SLIDE MOTOR
) OFF
OFF-.
IN
ON
Memory lever d: 1
19X0660
FRONT HEIGHT
MOTOR
ll
,pOFF
IN
UP
REAR HEIGHT
MOTOR
,>OFF OFF%,
IN
ON
I
1
19X061 7
CONSTRUCTION AND OPERATION
RECLINING ADJUSTMENT MECHANISM WITH MEMORY
If the seatback is raised after being inclined to the front, it
can be returned to the original angle set in memory by previously
setting the seatback angle in memory.
Furthermore, even after it is reclined at any angle, if the seatback
is raised after being inclined to the front, it can be returned
to the original angle set in memory.
The reclining memory mechanism consists of a memory lever,
memory plate, guide plate, guide lever and spring.
(1) Set the seatback to the position to be memorized, and
push the memory lever.
