6-6
INTERIOR
-
Seat
I
Memory
lever4
’
19X0661
19X0662
Guide lever
Guide
plate
Guide lever
19X0663
\
bide
plate
19X0664
Memory range
A
19X0659
(2) When the memory lever is pushed, it releases the meshing
of the memory plate and memory lever, and the memory
plate is rotated by the spring force and contacts the guide
plate.
d
When the memory lever is released, the lever engages
with the memory plate, completing the memorizing opera-
tion.
(3) Pull the reclining adjuster lever and fold the
seatback
for-
ward.
(4) Raise the seatback.
As the guide lever is now held by the guide plate, the
reclining gear cannot be locked.
:
i
(5) Raise the
seatback
further
Then the memory plate contacts the position A of the guide
plate and the guide plate starts to rotate.
When the memorized position is reached, the guide plate
releases the guide lever and the reclining gear is locked
to hold the
seatback
in position.
(6) The memory range is between A and
6
in the illustration.
If the memory lever is operated at a position between
B
and C, position
6
is memorized.
