POWER TRAIN
-
Automatic Transaxle
2-51
Reverse Gear
Reverse clutch applied
(turns front sun)
Low-reverse clutch applied
(holds rear
annulus
front carrier)
In reverse, input power is through the reverse clutch.
rotates the front carrier assembly pinions. The front
When applied, the reverse clutch drives the front
carrier is being held by the
UR
clutch so the pinions
sun gear through the overdrive hub and shaft. The
are forced to rotate the
Jnt
annulus/rear
carrier
ii
UR
clutch is applied to hold the front carrier/rear
assembly in the reverse direction. Output torque
annulus
assembly stationary. The front sun gear
is provided, in reverse, with a gear ratio of
2.21::1.
Transfer System
The
F4ACl
transaxle uses a transfer gear system to transfer
power from the output shaft of the rear carrier to the transfer
shaft. The gear that is splined and bolted to the output shaft
of the rear carrier
i,s
called the output shaft transfer gear. It
supplies power to the transfer shaft transfer gear which is
splined and retained by a large nut to the transfer shaft. The
bolt and nut that retain the transfer gears to each shaft must
be tightened to the proper torque specification. Proper torque
is essential for two reasons; to keep the gears on the shafts
and to maintain the bearing settings that provide for long life
of the system.
Both gears have helical cut teeth designed for quiter operation.
The overall gear ratio of the transaxle is in part determined
by the transfer gear ratio.
