I-64
ENGINE <TURBO>
-
General Information
ENGINE
<TURBO>
GENERAL INFORMATION
d
N7lSAOlAA
This 4G63-DOHC engine with turbocharger is essentially the same as the one currently used for Eclipse.
MAJOR SPECIFICATIONS
Items
Specifications
Total displacement
cm3
(cu.in.)
1,997 (121.9)
Bore x Stroke
mm (in.)
85.0 (3.35) x 88.0 (3.46)
Compression ration
8.5
Combustion chamber
Pentroof
type
Camshaft arrangement
DOHC
Valve timing
Intake
Open
21’
BTDC
Close
51’
ABDC
Exhaust
Open
57” BBDC
Close
15” ATDC
Fuel system
Electronic control multipoint fuel injection
Rocker.arm
Roller type
Lash adjuster
Equipped
84
86
