POWER TRAIN
-
Propeller Shaft
2-103
PROPELLER
SHAFT
N72ZEOOM
L
The AWD vehicles have a
3-section,
4-joint
type
noise characteristics, In keeping with adoption of
propeller shaft with center bearings. The center
the compact center bearing, the insulator for
installa-
bearing, provided with front and rear oil seals, is
tion of the bearing to the body has been changed
compact, lightweight and has excellent vibration and
in shape to further reduce vibration.
SPECIFICATIONS
r
Item
Propeller
shaft
Type
Lenath x O.D. mm (in.)
1
Front
Specifications
4-joint
propeller shaft
676.5 x 65 (26.63 x 2.56)
Universal
joint
Center
642.5 x 65 (25.30 x 2.56)
Rear
634.5 x 50.8 (24.98 x 2.00)
Type
No.
1,2,4
No. 3
Cross type
Equal velocity type
Lubrication
Cross type joint journal O.D.
Constant velocity joint O.D.
Pre-packed
mm (in.) 14.689
(.5783)
mm (in.) 94 (3.7)
NOTE
Propeller shaft length indicates the length between center points of each joint.
ii
CONSTRUCTION DIAGRAM
Rear propeller shaft
/
Center prop
eller
shaft
Center bearing
/
-.sds-Tv
Heat 1
protector
7
Front propeller shaft
Center bearing
seals
10NOOlO
Insulator
