Mitsubishi ECLIPSE Technical Information Manual

POWER TRAIN - Automatic Transaxle
2-49
First Gear
L
Underdrive clutch applied
(turns rear sun)
Low-reverse clutch applied
(holds rear annulus/front carrier)
In first gear range, torque input is through the under-
to “walk around” the inside of the stationary rear
drive clutch to the underdrive hub assembly. The
annulus gear. ‘The pinions are pinned to the rear ’
underdrive hub is splined to the rear sun gear. When
carrier and cause the rear carrier assembly to rotate
the underdrive clutch is applied, it rotates the under-
as they “walk around” the annulus gear. This pro-
drive hub and rear sun gear. The UR clutch is applied
vides the torque output for first gear. The other plane-
to hold the front carrier/rear annulus (ring gear)
tary gearset components are freewheeling. The first
assembly.
gear ratio is 2.84:1.
L
The rear sun gear drives the rear planetary pinion
gears. The rear planetary pinion gears are forced
Second Gear
Underdrive clutch applied
(turns rear sun)
2-4 clutch applied
(holds front sun)
id
Second gear is achieved by having both planetary
rear pinions rotate the rear annulus/front carrier as-
gear sets contribute to torque multiplication. As in
sembly. The pinions of the front carrier will “walk
first gear, torque input is through the underdrive
around” the stationary front sun gear. This transmits
clutch to the rear sun gear. The 2-4 clutch is applied
torque to the front annulus/rear carrier assembly
to hold the front sun gear stationary. The rotating
which provides output torque and a gear ratio of
rear sun gear turns the rear planetary pinions. The
1.57:1.
