DRIVE-CONTROL COMPONENTS - Front Sumension
SPECIFICATIONS
items
Suspension type
Wheel alignment
Camber
Caster
Toe-in
mm (in.)
Coil spring
Wire dia. x O.D. x
free length mm (in.)
Identification color
Spring constant
N/mm (Ibs./in.)
Shock absorber
Type
Medium price
High price
M/T
A/T
M/T
A/T
Multi-link type
-0”05’ Ik 30’
-0”20’ f 30’
4”40’ f 1030’
4”40’ f 1030’
0+3(Of.12)
0+3(Of.12)
13.1 x71.1 -
13.2x71.2-
12.9 x 70.9 -
111.1 x 309.5
13.1 x 71.1 -
111.2 x 315.5 110.9 x 300.5
(52 x 2.80 -
111.1 x 306.5
(52 x 2.80 -
4.37 x 12.19)
(51 x 2.79 -
(.52 x 2.80 -
4.38 x 12.42)
4.37 x 11.83)
White + Pink
4.37 x 12.07)
White + Gray Yellow + Pink
Yellow + Gray
43.0 (245)
43.0 (245)
43.0 (245)
43.0 (245)
Stroke
mm (in.)
Damping force
[at 0.3 m/set. (.9 ft./set.)]
Expansion
N (Ibs.)
Contraction
N (Ibs.)
Hydraulic cylindrical double-acting type
118 (4.65)
1,265 - 1,677 (284 - 377)
431 - 647 (97 - 146)
Items
Premium price
FWD
AWD
M/T A/T
M/T NT
Suspension type Multi-link type
Wheel alignment
Camber -0”20’ zk 30’ -0”05’ f 30’
Caster
4”40’ zk l”30’
4”40’ * 1030’
Toe-in mm (in.) 0+3(0*.12)
0*3(0*.12)
Coil spring
Wire dia. x O.D. x 13.1 x 71.1 - 13.2x71.2-
free length
13.3x71.3-
mm (in.)
13.5 x 71.5 -
111.1 x 306.5
111.2 x 312.5
111.3 x 312.0
(.52 x 2.80 -
111.5 x 317.5
(52 x 2.80 -
4.37 x 12.07)
(.52 x 2.81 -
4.38 x 12.30)
(.53 x 2.81 -
Identification color
4.38 x 12.28)
Yellow + Gray
4.39 x 12.50)
Yellow +
Green +
Light Blue Light Blue
Green + Purple
Spring constant
N/mm (Ibs./in.) 43.0 (245)
43.0 (245)
46.4 (265)
46.4 (265)
Shock absorber
Type
Hydraulic cylindrical double-acting type
Stroke mm (in.)
Hydraulic cylindrical double-acting type
118 (4.65)
Damping force
118 (4.65)
[at 0.3 mkiec. (.9 ft./set.))
Expansion N (Ibs.)
1,432 - 1,902 (322 - 428)
Contraction
1,471 - 1,961 (331 - 441)
N (Ibs.)
470 - 706 (106 - 159)
559-814(126-183)
