EQUIPMENT
-
ETACS
7-19
Item
Function and Summary of Operation
Seat belt warning tim-
er
fuction
<Warning
light>
When the ignition key is turned on,
ignition
ON
switch
I-------
the seat belt warning light flashes
OFF
for 6 seconds (4 times).
H signal
Timer output
&r!r~N)
I
(Light OFF)
-p+=+
6sec.
----t
<Buzzer>
If the driver’s seat belt is not worn
when the ignition switch is turned to
the ON position, the buzzer sounds
intermittently for six seconds, urg-
ing the driver to wear the seat belt.
Ignition switch
::,n
;.egp
swtich
ru
Timer output
16X0875
Central door lock timer When the driver’s door is locked by
function
means of its key or inside lock
Door lock
knob, all doors can be locked.
actuator (LH)
$pF)
Al
With the driver’s door unlocked, un-
locking for the second time by
means of the key unlocks all other
Door lock
key cylinder
doors.
switch (LH)
:ruu
Timer output
LK
J&l--Fi
16X0876
Power window timer
function
When the ignition key is turned off,
the ETACS timer function is acti-
vated, and the power window can
be opened and closed using the
power window switch for 30
se-
conds.
The power window timer stops,
however, if a door or
liftgate
is
opened within 30 seconds.
Ignition
switch
EF
Door switch,
liftgate switch”‘, OFF (closed)
kmaw
ON (open)
compartment
light switch*2
ON
’
Trmer
++J--$%
OFF ,
j--
output
30 sec.
30 sec.
!jPTE
l
21
Vehicles with theft-alarm system.
Vehicles without theft-alarm system.
16X0882
