EQUIPMENT
-
Heater and Air Conditioning
7-31
HEATER
AND
AIR
CONDITIONING
NiT’ZLOOAA
The heating system is a high-performance and
low-
noise full-air-mix system that provides a two-layer
stratified airflow. It features an independent
face-lev-
el
air flow and cool air by-passing functions.
The air conditioning system is essentially the same
as the conventional ones, but they incorporate a
new CFC-free refrigerant
(R134a)
system that uses
hydro fluorocarbon (HFC) containing hydrogen
atoms as the refrigerant gas to meet the CFC control
regulations that call for protection of the ozone layer.
FEATURES
Improvement in comfort
/
L
Protection of global
environment
1. Full-air-mix heater providing two-layer stratified air flow.
2.
Cool air by-passing function capable of sending fresh air
to the face even with the heater unit in operation.
3.
Independent face-level air flow function capable of sending
air constantly from the side ventilators.
4. Scroll type variable delivery air compressor that offers
improved cooling performance and quietness. <Turbo>
Independent face-level air flow from side ventilators.
Adoption of new refrigerant
(R134a)
system.
1.
Adoption of flange fitting design and O-ring slip-off prevent-
ing construction for piping joints to improve serviceability
and reliability.
2. Compressor lock controller for protecting the drive belt
when compressor is locked. <Non-turbo>
SPECIFICATIONS
I
LJ
Item
Heater unit
Type
Heater control switch
Compressor
Model
<Turbo>
<Non-turbo>
Dual pressure switch
High pressure switch
Low pressure switch
Refrigerant and quantity
Specifications
Two-way-flow full-air mix system
Dial and lever type
Scroll type
cMSC
105
CVS>
Inclined-plate type
<lOPAl
7C>
kPa
(psi)
OFF: 3,140 (456) ON: 2,550 (370)
OFF: 200 (29)
ON: 220 (32)
g (oz.)
R134a
(HFC-134a),
Approx. 700-740 (24.69-26.10)
To Next Page
