10 Input Wiring Procedures
10.5 Pulse Catch (M8170 to M8175)
128
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
10.5 Pulse Catch (M8170 to M8175)
The PLC (main unit) is provided with a pulse catch function and has 6 pulse catch input points.
For details on programming, refer to the programming manual.
10.5.1 Allocation of special memories to input numbers (ON duration of input signals)
10.5.2 Cautions for pulse catch
1. Non-overlap of input numbers
The input terminals X000 to X005 can be used for high-speed counter, input interruption, pulse catch, speed
detection (SPD) instructions and general-purpose input.
Take care not to overlap the input numbers.
Example:
When the C235, C241, C244, C246, C247, C249, C252 and C254 is used, X000 is occupied. Therefore, it is
impossible to use pulse catch input contact M8170.
Input number Contact on sequence program ON duration of input signal
X000 M8170
10 s or more
X001 M8171
X002 M8172 50 s or more
X003 M8173
10 s or more
X004 M8174
X005 M8175 50 s or more
