16 Input/Output Extension Blocks

16.4 FX2N-8EX-ES/UL, FX2N-16EX-ES/UL (24V DC Sink/Source Input)

220

FX3G Series Programmable Controllers

User's Manual - Hardware Edition

16.4.2 Parts identification and terminal arrangement

FX2N-8EX-ES/UL

2N-16EX-ES/UL

When an input (X) number is assigned, 8 points on the upper side will be used for the lower input numbers,

and 8 points on the lower side will be used for the higher input numbers.

With cover

Input indicator

lamps

(LED lamps)

Without cover

Rear line

extension

connector

S/S

With cover

Input indicator

lamps

(LED lamps)

Input indicator

lamps

(LED lamps)

Without cover

Rear line

extension

connector

S/S X1

X5 X7X6 X0 X1

Lower

numbers

Higher

numbers
