Mitsubishi FX3G Series User Manual

Appendix A: Special Device List
366
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
Appendix A-4 Analog special adapters[M8280 to M8299 and D8280 to D8299]
Appendix A-4-2 Special data registers (D8280 to D8299)
Number
Operation and function
FX3U-4AD-ADP FX3U-4DA-ADP FX3U-4AD-PT(W)-ADP FX3U-4AD-TC-ADP
1st analog special adapter
D 8280 Input data Ch1 Output data Ch1
Ch1 temperature
measurement data
Ch1 temperature
measurement data
D 8281 Input data Ch2 Output data Ch2
Ch2 temperature
measurement data
Ch2 temperature
measurement data
D 8282 Input data Ch3 Output data Ch3
Ch3 temperature
measurement data
Ch3 temperature
measurement data
D 8283 Input data Ch4 Output data Ch4
Ch4 temperature
measurement data
Ch4 temperature
measurement data
D 8284
Averaging time for Ch1
(1 to 4095)
Not used
Averaging time for Ch1
(1 to 4095)
Averaging time for Ch1
(1 to 4095)
D 8285
Averaging time for Ch2
(1 to 4095)
Not used
Averaging time for Ch2
(1 to 4095)
Averaging time for Ch2
(1 to 4095)
D 8286
Averaging time for Ch3
(1 to 4095)
Not used
Averaging time for Ch3
(1 to 4095)
Averaging time for Ch3
(1 to 4095)
D 8287
Averaging time for Ch4
(1 to 4095)
Not used
Averaging time for Ch4
(1 to 4095)
Averaging time for Ch4
(1 to 4095)
D 8288 Error status Error status Error status Error status
D 8289 Model code: 1 Model code: 2
Model code: PT: 20
PTW: 21
Model code: 10
2nd analog special adapter
D 8290 Input data Ch1 Output data Ch1
Ch1 temperature
measurement data
Ch1 temperature
measurement data
D 8291 Input data Ch2 Output data Ch2
Ch2 temperature
measurement data
Ch2 temperature
measurement data
D 8292 Input data Ch3 Output data Ch3
Ch3 temperature
measurement data
Ch3 temperature
measurement data
D 8293 Input data Ch4 Output data Ch4
Ch4 temperature
measurement data
Ch4 temperature
measurement data
D 8294
Averaging time for Ch1
(1 to 4095)
Not used
Averaging time for Ch1
(1 to 4095)
Averaging time for Ch1
(1 to 4095)
D 8295
Averaging time for Ch2
(1 to 4095)
Not used
Averaging time for Ch2
(1 to 4095)
Averaging time for Ch2
(1 to 4095)
D 8296
Averaging time for Ch3
(1 to 4095
Not used
Averaging time for Ch3
(1 to 4095)
Averaging time for Ch3
(1 to 4095)
D 8297
Averaging time for Ch4
(1 to 4095)
Not used
Averaging time for Ch4
(1 to 4095)
Averaging time for Ch4
(1 to 4095)
D 8298 Error status Error status Error status Error status
D 8299
Model code: 1 Model code: 2
Model code: PT: 20
PTW: 21
Model code: 10

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
