Mitsubishi FX3G Series User Manual

Appendix A: Special Device List
363
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
21
Memory Cassette
22
Battery
A
Special Devices (M8000-,D8000-)
B
Instruction List
Appendix A-3 Analog expansion boards[M8260 to M8279 and D8260 to D8279]
Appendix A-3-2 Special data registers (D8260 to D8279)
Number
Operation and function
FX3G-2AD-BD FX3G-1DA-BD
Compatible
Versions
Ver.1.10 or later Ver.1.10 or later
1st analog expansion board
D 8260 Input data Ch1 Output data
D 8261 Input data Ch2 Not used
D 8262 Not used Not used
D 8263 Not used Not used
D 8264
Averaging time for Ch1
(1 to 4095)
Not used
D 8265
Averaging time for Ch2
(1 to 4095)
Not used
D 8266 Not used Not used
D 8267 Not used Not used
D 8268 Error status Error status
D 8269 Model code: 3 Model code: 4
2nd analog expansion board
D 8270 Input data Ch1 Output data
D 8271 Input data Ch2 Not used
D 8272 Not used Not used
D 8273 Not used Not used
D 8274
Averaging time for Ch1
(1 to 4095)
Not used
D 8275
Averaging time for Ch2
(1 to 4095)
Not used
D 8276 Not used Not used
D 8277 Not used Not used
D 8278 Error status Error status
D 8279 Model code: 3 Model code: 4
