6 Examination of System Configuration
6.8 Number of Input/Output (Occupied) Points and Current Consumption
72
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
6.8 Number of Input/Output (Occupied) Points and Current Consumption
The following tables show the number of input/output points or the number of input/output occupied points for
each type of device, along with the power supply type and current consumption values needed for selecting a
product.
• Number of input/output points or input/output occupied points on each type of device
• Output current of 24V DC service power supply of main units
• Output current of 5V DC power supply and 24V DC service power supply of input/output powered
extension units
• Current consumed by input/output extension blocks and special function blocks
The current consumption is determined differently in the following cases.
• In the input/output powered extension unit, 5V DC and internal 24V DC are supplied via extension cables.It
is necessary to calculate the current consumption.Subtract the current consumption of the internal 24V DC
from the 24V DC service power supply.
• The special function units/blocks connected to the AC power type main unit or to the 24V DC service
power supply terminal of the input/output powered extension unit consume the external 24V DC. Include
the current in the calculation of current consumption.
When the terminal is connected with an external power supply, the current is not included in the calculation
of current consumption.
6.8.1 [A] Main units
*1. Each number inside ( ) indicates the number of occupied points.
Use numbers inside ( ) when calculating the total number of input/output points.
6.8.2 [B] Input/output powered extension units/blocks
1. Input/output powered extension units
No. Type
Input/output Output current (mA)
Number of input/
output points
[points]
Input/output
[points]
24V DC service power supply
AC power supply/24V DC input/transistor output type
FX3G-14MT/ES
14(16)
*1
8/6(8)
400
FX3G-24MT/ES
24(32)
*1
14(16)/10(16)
FX3G-40MT/ES 40 24/16
FX3G-60MT/ES
60(64)
*1
36(40)/24
No. Type
Input/output Output current (mA)
Number of input/
output points
[points]
Input/output
[points]
5V DC power supply
24V DC service
power supply
FX2N-32ER-ES/UL 32 16/16
690
250
FX2N-32ET-ESS/UL 32 16/16
FX2N-32ER 32 16/16
FX2N-32ES 32 16/16
FX2N-32ET 32 16/16
FX2N-48ER-ES/UL 48 24/24
460
FX2N-48ET-ESS/UL 48 24/24
FX2N-48ER 48 24/24
FX2N-48ET 48 24/24
A
A1
B
B1

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
