20 Terminal Block
20.5 FX-16E-TB, FX-32E-TB
322
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
20.5.2 Example of input external wiring
1. When connected to an FX2N-16EX-C (sink input) input extension block
20.5.3 Output external wiring
1. When connected to an FX2N-16EYT-C (sink output) output extension block
WIRING PRECAUTIONS
Do not wire vacant terminals externally.
Doing so may damage the product.
WIRING PRECAUTIONS
Do not wire vacant terminals externally.
Doing so may damage the product.
1 3
4
5
60 2
7 1 3
0 2 4
5
6
7
24+
7
6
5
4
3
2
1
0 0
1
2
3
4
5
6
7
24V
DC
Input numbers in
the FX2N-16EX-C
24+
24+
24+
0 to 7 (Higher Nos.) 0 to 7 (Lower Nos.)
1 3
4
5
60 2
7 1 3
0 2 4
5
6
7
Vacant
terminal
7
6
5
4
3
2
1
0 0
1
2
3
4
5
6
7
COM
COM
PLC's
output No.
MC1 MC2
COM
COM
COM
COM
COM
COM
COM
COM
0 to 7 (Higher Nos.) 0 to 7 (Lower Nos.)
24V
DC
