5 Version Information and Peripheral Equipment Connectability
5.6 Other Peripheral Equipment Applicability
52
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
5.6 Other Peripheral Equipment Applicability
5.6.1 Other Peripheral Equipment Applicability
*1. The F940GOT and ET-940 whose version is former than Ver.1.10 do not support the transparent (2-
port) function of the GX Developer.
Model name Applicability Remarks
GOT1000 Series Applicable
This series is compatible with the FX3G PLC when GT Designer2 Ver. 2.85P or later is
used.
GT15 and GT11:
Standard monitor OS[03.14.**]or later
Communication driver MELSEC-FX[03.14.**]or later
Option OS List editor for MELSEC-FX[03.14.**]or later
GT10:
Standard monitor OS[01.10.**]or later
Communication driver MELSEC-FX[01.06.**]or later
This series is subject to the following restrictions when connected using unsupported
standard monitor OS, communication driver or option OS.
Contents of restrictions
Programming is enabled only in the function ranges such as instructions, device ranges
and program sizes available in the FX1N and FX1NC PLCs.
The list editor function for MELSEC-FX is not available. When using the list editor
function for MELSEC-FX, upgrade the standard monitor OS, communication driver and
option OS to the version compatible with the FX3G PLC.
Check the applicability of other items in the GOT manual.
F940WGOT Not available
The following restriction applies when connected.
Contents of restrictions
Programming is enabled only in the function ranges such as instructions, device ranges
and program sizes available in the FX1N and FX1NC PLCs.
For applicable models, refer to the GOT manual.
For connection using the 2-port interface function
*1
, refer to Section 5.5.
F940GOT F940 Handy GOT Not available
F930GOT(-K) Not available
F920GOT(-K) Not available
ET-940 Not available
FX-10DM(-SET0) Not available
The following restriction applies when connected.
Contents of restrictions
Programming is enabled only in the function ranges such as instructions, device ranges
and program sizes available in the FX
1N and FX1NC PLCs.
For supported models and device ranges, refer to the FX-
10DM USER'S MANUAL
(Manual No. JY992D86401).
FX-10DU Not available
The following restriction applies when connected.
Contents of restrictions
It is limited to the device range and function range supported by the highest class model
(FX1N or FX2N ) applicable in the product version.
For supported models and device ranges,
refer to the FX-10DU-E/FX-20DU-E User's Manual
(Manual No. JY992D54801).
