Mitsubishi FX3G Series - External Dimensions

16 Input/Output Extension Blocks
16.2 FX2N-8ER-ES/UL (24V DC Sink/Source Input, Relay Output)
215
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
Input/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
16.2.3 External dimensions
43(1.7")
9(0.36")
80(3.15")
(mounting hole pitch)
87(3.43")
90(3.55")
Unit:mm(inches)2- 4.5 mounting holes
