Mitsubishi FX3G Series User Manual

8 Installation In Enclosure
8.2 Layout in Enclosure
85
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
1
Introduction
2
Features and Part Names
3
Product Introduction
4
Specifications
5
Version and Peripheral Devices
6
System Configuration
7
Input/Output Nos., Unit Nos.
8
Installation
9
Preparation and Power Supply Wiring
10
Input Wiring
8.1.2 Spaces in enclosure
Extension devices can be connected on the left and right sides of the main unit of the PLC.
If you intend to add extension devices, keep necessary spaces on the left and right sides.
1. Configuration without extension cable
2. Configuration in 2 stages with extension cable
8.2 Layout in Enclosure
The PLC components can be laid out in one stage or in two stages, upper and lower. The connecting
procedures in each case are explained below.
8.2.1 1-stage layout
FX3G Series
main unit
FX2N-16EX FX2N-16EYT
A
A
A
A
A
50mm (1.97")
Other equipment
Other
equipment
A
A
A
A
A
Input/output
powered
extension unit
FX
2N
-
16CCL-M
A
Other
equipment
A
FX3G Series
main unit
FX
3U
-4AD-
ADP
FX
3G
-CNV-
ADP
A
FX2N-16EX
Extension cable
·FX
0N-65EC
·FX
0N-30EC
FX2N-16EYT
FX2N-CNV-
BC
50mm (1.97")
Input/output powered extension units/blocks
Special function blocks
FX 3G Series
main unit
Input/output
powered
extension units
For the dimensions of each product, refer to the
external dimensions.
Special
adapter
Extension
block
Extension
block
Extension
block
Extension
block
A
Connector
conversion
adapter
A
A
50mm (1.97")

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
