Mitsubishi FX3G Series User Manual

3 Introduction of Products
3.2 Connector Types and Cables for Program
35
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
1
Introduction
2
Features and Part Names
3
Product Introduction
4
Specifications
5
Version and Peripheral Devices
6
System Configuration
7
Input/Output Nos., Unit Nos.
8
Installation
9
Preparation and Power Supply Wiring
10
Input Wiring
3.2.1 Programming tool
The following programming tool supports FX3G Series PLCs.
→ For more information, refer to 5. Version Information and Peripheral Equipment Connectability.
3.2.2 Communication cables
*1. The following USB cables are applicable.
3.2.3 Converters and interface
*1. When the programming software is not applicable to FX3G, the converter is applicable only to 9,600 or
19,200 bps.
Model name Description
GX Developer
Version 8.72A or later of SW D5C-GPPW-J and SW D5C-GPPW-E supports FX3G.
Although the tool earlier than version 8.72A can be used for programming by selecting FX1N(C), restrictions
will be made on programming.
Model name Description
USB cable
USB cable
*1
3m
(9’10")
USB A plug USB MINI B plug
For connection between personal computer and FX
3G programming port (USB)
RS-232C cable
F2-232CAB-1
3m
(9’10")
D-SUB 9Pin D-SUB 25Pin
For connection between personal computer and RS-232C/RS-422 converter
F2-232CAB
3m
(9’10")
D-SUB 25Pin D-SUB 25Pin
For connection between personal computer and RS-232C/RS-422 converter
F2-232CAB-2
3m
(9’10")
Half-pitch 14-pin D-SUB 25Pin
For connection between personal computer and RS-232C/RS-422 converter
FX-232CAB-1
3m
(9’10")
D-SUB 9Pin D-SUB 9Pin
For connection between personal computer and RS-232C/RS-422 converter FX3G-232-BD,
FX3U-232ADP(-MB)
FX-232CAB-2
3m
(9’10")
Half-pitch 14-pin D-SUB 9Pin
For connection between personal computer and RS-232C/RS-422 converter FX3G-232-BD,
FX3U-232ADP(-MB)
RS-422 cable
FX-422CAB0
1.5m
(4’11")
D-SUB 25Pin MINI DIN 8Pin
For connection between RS-232C/RS-422 converter and FX3G programming port FX3G-422-BD
Model name Description
MR-J3USBCBL3M USB cable 3m(9’10")
GT09-C30USB-5P USB cable to transfer personal computer data (USB A plug) 3m(9’10")
Model name Description
RS-232C/RS-422 Converters
FX-232AWC-H
*1
RS-232C/RS-422 converter (high-speed type)
Communication speed: Applicable to 9,600 to 115,200 bps .
FX-232AW
RS-232C/RS-422 converters
Communication speed: Applicable to 9,600/19,200 bps
FX-232AWC
1
2
3
4
3
1
1
1
4
4
2

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
