16 Input/Output Extension Blocks

16.3 FX2N-8ER (24V DC Sink Input, Relay Output)

218

FX3G Series Programmable Controllers

User's Manual - Hardware Edition

16.3.3 External dimensions

43(1.7")

9(0.36")

80(3.15")

(mounting hole pitch)

87(3.43")

90(3.55")

Unit:mm(inches)2- 4.5 mounting holes
