FX3G Series Programmable Controllers
User's Manual - Hardware Edition
1
Introduction
2
Features and Part Names
3
Product Introduction
4
Specifications
5
Version and Peripheral Devices
6
System Configuration
7
Input/Output Nos., Unit Nos.
8
Installation
9
Preparation and Power Supply Wiring
10
Input Wiring
2) Extension devices (Chapter 15 to Chapter 18)
3) Optional products (Chapter 19 to Chapter 22)
4) Others (Appendix A to Appendix B)
Division Outline Reference
Input/output powered extension
units
This chapter contains explanations for the input/output specifications, external
dimensions and terminal layout for each product.
Chapter 15
Input/output extension blocks Chapter 16
Extension power supply unit
(FX3U-1PSU-5V)
This chapter contains explanations of specifications for the extension power
supply unit and external dimensions.
Chapter 17
Extension products for special
functions, such as analog control
and communication
This chapter contains explanations for the external dimensions and terminal
layout (For details, refer to the manual for each extension device).
Chapter 18
Division Outline Reference
Display module
This chapter contains explanation of the specifications, external dimensions,
mounting procedures and operating procedures for display modules(FX3G-5DM).
Chapter 19
FX Series terminal blocks
This chapter contains explanations of the procedures for wiring FX-16/32E -TB.
Chapter 20
Memory cassette
This chapter contains explanations of the specifications for the memory cassette
and the installation procedures.
Chapter 21
Battery
This chapter contains explanations of the procedures for replacing the battery and
detecting battery voltage drop.
Chapter 22
Division Outline Reference
List of special devices
This chapter contains an explanation list of the special auxiliary relays (M8000 to
M8511) and special data registers (D8000 to D8511)
(For details, refer to the programming manual.)
Appendix A
List of instructions
This chapter contains an explanation list of the basic instructions and applied
instructions
(For details, refer to the programming manual.)
Appendix B

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
