16 Input/Output Extension Blocks

16.1 Outline

212

FX3G Series Programmable Controllers

User's Manual - Hardware Edition

3. For output extension

:Sink [-common], :Source [+common]

Model

Input Output

Connection

type

Type

Number

of points

Common

system

Type

Number

of points

Common

system

Relay output type

FX2N-8EYR-ES/UL - - - Relay 8 - Terminal block

FX2N-8EYR - - - Relay 8 - Terminal block

FX2N-16EYR-ES/UL - - - Relay 16 - Terminal block

FX2N-16EYR - - - Relay 16 - Terminal block

Dedicated to sink output only

FX2N-8EYT - - - Transistor 8 Terminal block

FX2N-8EYT-H - - - Transistor 8 Terminal block

FX2N-16EYT - - - Transistor 16 Terminal block

FX2N-16EYT-C - - - Transistor 16 Connector

FX2N-16EYS - - - Transistor 16 - Terminal block

Dedicated to source output only

FX2N-8EYT-ESS/UL - - - Transistor 8 Terminal block

FX2N-16EYT-ESS/UL - - - Transistor 16 Terminal block

Sink Source

Sink

Source
