Mitsubishi FX3G Series User Manual

1 Introduction
1.1 Introduction of Manuals
20
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
Other manuals
When using each product, refer also to the User's Manual - Hardware Edition for the PLC main unit to be installed.
Variable analog potentiometers
Supplied
with
product
FX3G-8AV-BD
Installation Manual
JY997D33701
Procedures for handling the 8-ch variable analog
potentiometers expansion board
When using, refer also to FX3G/FX3U/FX3UC Series
Programming Manual -Basic & Applied Instruction
Edition
-
Connector conversion
Supplied
with
product
FX3G-CNV-ADP
Installation Manual
JY997D32301
Procedures for handling the conversion function
expansion adapter for connectors for connecting
communication and analog special adapters
-
Battery (maintenance option)
Supplied
with
product
FX3U-32BL Battery
Hardware Manual
JY997D14101 Battery life and handling procedures -
Memorry cassette
Supplied
with
product
FX3G-EEPROM-32L
Installation Manual
JY997D32401
Specifications and operating procedures of the
memory cassette
-
Display module
Supplied
with
product
FX3G-5DM
Installation Manual
JY997D33801
Procedures for mounting and handling the display
module
-
Extension power supply unit
Supplied
with
product
FX3U-1PSU-5V
Installation Manual
JY997D22501
Specifications and operating procedures of the
extension power supply unit
-
Manual title Manual number Contents
Model name
code

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
