Mitsubishi FX3G Series User Manual

2 Features and Part Names
2.1 Major Features
24
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
[Pulse output function]
When output terminals in the transistor output
type main unit are used, pulses (open collector
outputs) of up to 100kHz can be output
simultaneously to 3 axes
*1
(Y000, Y001 and
Y002).
*1. 2 axes (Y000 and Y001) in 14-point and
24-point type main units
Using a number of instructions programming is
simplified.
→ Refer to Positioning Control Edition.
[Various positioning instructions]
→ Refer to Positioning Control Edition.
3. Display functions (display module)
(Supported in Ver. 1.10 or later)
FX3G-5DM Display Module (option) can be
incorporated in the PLC.
[Monitor/test function]
Devices can be monitored and tested by
operating the buttons on the display module.
The button operations can be inhibited by the
user program.
[Other functions]
On the display module, you can set the time,
adjust the contrast and display the PLC version
and error codes.
→ Refer to 19. Display Module(FX3G-5DM) in
this manual.
4. Communication and network functions
The expansion board and special adapter for
each communication function can be connected.
[Kinds of communication functions]
• Programming communication through RS-
232C, RS-422 and USB
→ Refer to Data Communication Edition.
• N:N Network
→ Refer to Data Communication Edition.
• Parallel link
→ Refer to Data Communication Edition.
• Computer link
→ Refer to Data Communication Edition.
• Inverter communication
(Supported in Ver. 1.10 or later)
→ Refer to Data Communication Edition.
• Non-protocol communication through built-in
RS-422/RS-232C/RS-485
→ Refer to Data Communication Edition.
• CC-Link
- Master station
FX
2N-16CCL-M
- Intelligent device station
FX
3U-64CCL
- Remote device station
FX
2N-32CCL
→ Refer to the manual for each product.
• CC-Link/LT
- Master station : FX
2N-64CL-M
- Remote I/O station, Remote device station
→ Refer to the manual for each product.
5. Analog functions
The special adapter and special function block
for each analog function are connected.
→ Refer to Analog Control Edition.
[Kinds of analog functions]
• Voltage/current input
• Voltage/current output
• Temperature sensor input (thermocouple and
platinum resistance thermometer sensor)
• Temperature control
Instruction Description
DSZR
Mechanical zero return instruction with DOG
search function
ABS
Instruction to read the current value from our
servo amplifier with absolute position (ABS)
detecting function
DRVI
Positioning (relative positioning) to specify the
movement from the current position
DRVA
Positioning (absolute positioning) to specify
the target position based on the current
value 0
PLSV
Instruction to change the pulse train output
frequency
TBL
Instruction for positioning based on batch
setting of positioning operation, moving
distance and speed

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
