Appendix B: Instruction List

Appendix B-3 Applied Instructions ... in Ascending Order of FNC Number

371

FX3G Series Programmable Controllers

User's Manual - Hardware Edition

Memory

Cassette

Battery

Special Devices

(M8000-,D8000-)

Instruction List

*1. Supported in Ver. 1.10 or later

FNC No. Mnemonic Function

Extension File Register Control

290 LOADR Load From ER

291 -

292 -

293 -

294 RWER Rewrite to ER

295 -

296 -

297 -

298 -

299 -
