V5A51 -
Specifications
23E-1-5
TORQUE SPECIFICATIONS
TRANSMISSION
Item Torque Nm
Output shaft support mounting bolt 23 ± 3
Upper valve body mounting bolt 11 ± 1
Park/neutral position switch mounting bolt 11 ± 1
Anchor plug 98 ± 15
Oil pan mounting bolt 11 ± 1
Oil filter mounting bolt 6 ± 1
Oil pump mounting bolt 23 ± 3
Cable end bracket mounting bolt 48 ± 6
Converter housing to transmission case tightening bolt 48 ± 6
Output shaft speed sensor mounting bolt 11 ± 1
Reduction brake piston nut 19 ± 3
Separating plate mounting bolt 6 ± 1
Solenoid support mounting bolt 6 ± 1
Transfer to transfer case adapter tightening bolt 35 ± 6
Transmission case to transfer case adapter tightening bolt 48 ± 6
Input shaft speed sensor mounting bolt 11 ± 1
Valve body mounting bolt 11 ± 1
Detent spring mounting bolt 6 ± 1
Manual control lever mounting nut 22 ± 3
Lower valve body mounting bolt 11 ± 1
Lower valve body cover mounting bolt 11 ± 1
AddedPWEE8920-I
E
Mar. 2000Mitsubishi Motors Corporation
