SERVICE SPECIFICATIONS
TRANSMISSION
Item Standard value
Direct planetary carrier mm 0.25 - 0.55
Underdrive clutch end play mm 1.6 - 1.8
Input shaft end play mm 0.25 - 0.81
Direct clutch end play mm 1.0 - 1.2
Overdrive clutch end play mm 2.0 - 2.2
Overdrive clutch return spring retainer end play mm 0 - 0.09
Second brake end play mm 1.49 - 1.95
Center support end play mm 0 - 0.16
Brake reaction plate end play mm 0 - 0.16
Reverse clutch end play mm 1.5 - 1.7
Low/reverse brake end play mm 1.65 - 2.11
TRANSFER
Item Standard value Limit
Input gear bearing end play mm 0 - 0.06 -
Countershaft gear end play mm 0 - 0.15 -
Countershaft gear bearing end play mm 0 - 0.08 -
2-4WD clutch hub end play mm 0 - 0.08 -
H-L clutch hub end play mm 0 - 0.08 -
Rear output shaft preload mm 0.12 - 0.24 -
Rear output shaft end play mm 0 - 0.12 -
Rear output shaft bearing end play mm 0 - 0.08 -
Rear output shaft annulus gear end play mm 0 - 0.08 -
Differential lock hub end play mm 0 - 0.08 -
Clearance between outer synchronizer ring and drive sprocket mm - 0.3
