V5A51 -
Reverse and Overdrive Clutch
23E-6-1
6. REVERSE AND OVERDRIVE CLUTCH
DISASSEMBLY AND ASSEMBLY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
12
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Apply automatic
transmission fluid to
all moving parts
before installation.
Disassembly steps
1. Seal ring
2. Snap ring
3. Input shaft
"
H
A 4. Snap ring
"
G
A 5. Reaction plate
"
G
A 6. Clutch disc
"
G
A 7. Clutch plate
"
F
A 8. Snap ring
"
E
A 9. Reaction plate
"
E
A 10. Clutch disc
"
E
A 11. Clutch plate
A
A
""
D
A 12. Snap ring
13. Spring retainer
"
A
A 14. D-ring
"
C
A 15. Return spring
16. Overdrive clutch piston
"
A
A 17. D-ring
"
B
A 18. Reverse clutch piston
"
A
A 19. D-ring
"
A
A 20. D-ring
"
A
A 21. D-ring
22. Reverse clutch retainer
AddedPWEE8920-I
