V5A51 -
Input Gear
23E-17-1
17. INPUT GEAR
DISASSEMBLY AND ASSEMBLY
1
2
3
4
5
6
Apply gear oil to all
moving parts before
installation.
Disassembly steps
"
B
A 1. Snap ring
A
A
""
A
A 2. Ball bearing
3. Snap ring (some model)
4. Cone spring (some model)
5. Sub gear (some model)
6. Transfer input gear
DISASSEMBLY SERVICE POINT
A
A
"
BALL BEARING REMOVAL
Use the special tool to remove the ball bearing.
ASSEMBLY SERVICE POINTS
"
A
A
BALL BEARING INSTALLATION
Use the special tools to install the ball bearing.
AddedPWEE8920-I
E
Mar. 2000Mitsubishi Motors Corporation
MD998801
MD998812
MD998826
