V5A51 -
Specifications
23E-1-13
FORM-IN-PLACE GASKET (FIPG)
The transmission has several areas where the form-in-place gasket (FIPG) is in use. To ensure that
the gasket fully serves its purpose, it is necessary to observe some precautions when applying the gasket.
Bead size, continuity and location are of paramount importance. Too thin a bead could cause leaks.
Too thick a bead, on the other hand, could be squeezed out of location, causing blocking or narrowing
of the fluid feed line. To eliminate the possibility of leaks from a joint, therefore, it is absolutely necessary
to apply the gasket evenly without a break, while observing the correct bead size.
Since the FIPG used in the transmission hardens as it reacts with the moisture in the atmospheric air,
it is normally used in the metallic flange areas.
Disassembly
The parts assembled with the FIPG can be easily disassembled without use of a special method. In
some cases, however, the sealant between the joined surfaces may have broken by lightly striking with
a mallet or similar tool. A flat and thin gasket scraper may be lightly hammered in between the joined
surfaces. In this case, however, care must be taken to prevent damage to the joined surfaces.
Surface preparation
Thoroughly remove all substances deposited on the gasket application surfaces, using a gasket scraper
or wire brush. Check to ensure that the surfaces to which the FIPG is to be applied is flat. Make sure
that there are no oils, greases an d foreign substances deposited on the application surfaces. Do not
forget to remove the old FIPG remaining in the bolt holes.
Form-in-place gasket application
When assembling parts with the FIPG, you must observe some precautions, but the procedures is very
simple as in the case of a conventional precut gasket.
Applied FIPG bead should be of the specified size and without breaks. Also be sure to encircle the
bolt hole circumference with a completely continuous bead. The FIPG can be wiped away unless it is
hardened. While the FIPG is still moist (in less than 15 minutes), mount the parts in position. When
the parts are mounted, make sure that the gasket is applied to the required area only. In addition, do
not apply any oil or water to the sealing locations or start the engine until a sufficient amount of time
(about one hour) has passed after installation is completed.
The FIPG application procedure may vary on different areas. Observe t h e procedure described in the
text when applying the FIPG.
LUBRICANTS
TRANSFER
Item Specified lubricant
Lip of transfer case oil seal MITSUBISHI genuine grease part No. 0101011 or
Lip of transfer case plate oil seal
equivalent
Lip of rear cover oil seal
AddedPWEE8920-I
E
Mar. 2000Mitsubishi Motors Corporation
