V5A51 -
Rear Output Shaft
23E-19-2
"
B
A
SNAP RING INSTALLATION
1. Install the thickest snap ring that can be fitted in the
snap ring groove of the rear output shaft.
2. Make sure that the rear output shaft bearing end play
meets the standard value.
Standard value: 0 - 0.08 mm
"
C
A
SNAP RING INSTALLATION
1. Install the thickest snap ring that can be fitted in the
snap ring groove of the annulus gear.
2. Make sure that the annulus gear end play meets the
standard value.
Standard value: 0 - 0.08 mm
AddedPWEE8920-I
E
Mar. 2000Mitsubishi Motors Corporation
