Mitsubishi V5A51 User Manual

V5A51 -
Transmission
23E-5-5
70
71
72
73
74
75
76
88
81
78
87
93
94
86
80
79
82
83
19
±
3Nm
85
23
±
3Nm
91
92
98
±
15 Nm
77
89
90
95
84
Apply automatic
transmission fluid to
all moving parts
before installation.
70. Snap ring
71. Center support
72. Thrust race No.8
73. Thrust bearing No.9
74. Direct annulus gear
75. Thrust bearing No.12
76. Direct planetary carrier
77. Seal ring
78. Seal ring
79. Snap ring
80. Reduction brake cover
81. O-ring
82. Snap ring
83. Reduction brake piston nut
84. Reduction brake piston
85. Seal ring
86. Reduction brake piston adjusting rod
87. Reduction brake spring
88. Direct clutch
89. Thrust bearing No.13
90. Reduction brake band
91. Anchor plug
92. O-ring
93. Output shaft support
94. Output shaft support gasket
95. Transmission case
AddedPWEE8920-I
E
Mar. 2000Mitsubishi Motors Corporation
