Mitutoyo LGH Series User Manual

19
3 Parameter Setting
No. 99MBC122A
No. Setting item
Description/Set values
(The values in bold indicate initial values.)
09 Unit system selection The unit for displayed values can be set to "mm" or "E units". E=1/25.4 mm.
After the unit is set, the initial value will not be restored even if the parameters
are re-initialized.
When the set value is set to 1 or 2, the UNIT indicator turns on.
0: mm
1: E 5/100,000 reading
2: E 1/10,000 reading
3: (Not available)
10 Output signal pitch You can set the output signal pitch of the gage head per axis.Since this prod-
uct does not allow input for the B-axis (INPUT B), the setting of the B-axis is
disabled.
0: (Not available)
1: 4 µm
2: (Not available)
3: (Not available)
11 Selection of counter
direction
You can set whether the numeral will increase or decrease when the spindle
is pushed in, per axis.Since this product does not allow input for the B-axis
(INPUT B), the setting of the B-axis is disabled.
0: + counting
1: - counting
12 Resolution You can set the resolution of the gage head per axis.Since this product does
not allow input for the B-axis (INPUT B), the setting of the B-axis is disabled.
0: (Not available)
1: (Not available)
2: 1 µm
3: 0.5 µm
4: 0.1 µm
5: 0.05 µm
6: 0.01 µm
7: (Not available)
8: (Not available)
13 µm decimal point
display
If enabled, the decimal point will be displayed at the µm position.
0: Disabled
1: Enabled
14 (Not used) 0:-
1:-
15 Smoothing Averages the counter value and then displays it. (This reduces uctuation
of the lowest-order digit.) You can specify the number of measurements to
average.
0: None
1: 16 times
2: 32 times
