Screen Descriptions
2-25
element
TM
Series
EB4A EB4 solid state device enable from SPA
EMDISP Emergency Dispatch
EMS Emergency Medical Service
EQ
In some jurisdictions a ring and string or seismic switch (or both) will be used to activate
earthquake operation. Earthquake view @ SYST IO > PROGRAMMED INPUTS, EQ, SS or EQ
CWT
EQ CWT Earthquake Counterweight
EQI Earthquake Input
EQR
Earthquake operation is a latching function that requires a manual reset which this switch
provides. Earthquake Reset @ SPB DIAG > SPB Inputs, see EQR.B
ESC
Fed by Firefighter’s Stop Switch, Car top switch, emergency exit contact, and SOS switch.
Emergency Stop Car @ System IO > System Inputs
ESCTO.B Emergency Switch Cutout enable, Safety Processor B @ SPB DIAG > SPB Outputs
ETH Ethernet
FB
Fed by fault bypass jumper on SCE-CPU. Fault Bypass @ SPB DIAG > SPB Inputs, see
FBYP.P Flag
FR2 CANCL In-Car Fire Service Car Call Cancel @ SYSTEM IO > PROGRAMMED INPUTS, FR2 Cancel
FR2 HOLD In-Car Fire Switch Hold @ System IO > PROGRAMMED INPUTS, FR2 HOLD
FR2 OFF In-Car Fire Switch OFF @ System IO > Programmed Inputs, FR2 OFF
FR2 ON In-Car Fire Switch ON @ System IO > Programmed Inputs, FR2 ON
FLO Fan Light Output @ SPA DIAG > SPA Flags also in CONFIG 01 > System Timers
FLPC Fan Light Power Control
FLPWR Car fan and light power control @ SPB DIAG > SPB Outputs, FLPWR.B
FLR GONG Floor Gong
FLT Fault
FLT BYP
Fault Bypass input on SCE-CPU board, view @ PLD DIAG> PLD INPUTS, FLT BYP JPR and
also @ SYST I/O, System Inputs, FLT BYP
FPM Feet Per Minute
FR Fault Reset @ PLD DIAG > PLD Inputs, FLT RST BTN
FR HAT Fire service light enable output @ System IO > Programmed Outputs
FR1 BUZZER Fire service buzzer enable output @ System IO > Programmed Outputs
FR1 LIGHT Fire service light, lobby, enable @ System IO > Programmed Outputs
FR1 OFF Fire recall switch off input @ System IO > Programmed Inputs
FR1 ON Fire recall switch on input @ System IO > Programmed Inputs
FR1 RESET Fire Recall reset input @ System IO > Programmed Inputs
FRA Fire Recall Alternate @ System IO > Programmed Inputs
FRS Fire Recall Main @ System IO > Programmed Inputs
FRSA Fire Recall Switch, this car Alternate @ System IO > Programmed Inputs
FRSM Fire Recall Switch Main
GOS (1/2) Governor Overspend switch In (1), Out (2)
GOV
Governor input that opens if car over speeds. Drops safety string and activates rope grip-
per. Governor
GP General purpose. Cycle Test I/O if used
GP PLD General Purpose output (PLD controlled)
GS/gate switch PLD gate switch monitor @ PLD DIAG > PLD Inputs
Table 2.4 Acronym Descriptions and Memory Locations
Acronym Description and Memory Location
