Configuration and Troubleshooting
2-26 Manual # 42-02-2P26
GSB Secondary gate switch monitor to PLD
HAPS Hydraulic Auxiliary Power Supply (MCE APS product for hydraulic elevators)
HC Hall Call
HCF Hall Call Front
HCT Hall Call Time. Defined time for doors to remain open @ SPA DIAG > Door Dwell Timers
HDB
From ON position of switch used to bypass hoistway doors. Also places car on inspection
simultaneously. Hoistway Door Bypass signal to Safety Processor B @ SPB DIAG > SPB
Inputs
HDBO
From OFF position of switch used to bypass hoistway doors. Used for monitoring switch.
Hoistway Door Bypass OFF @ SPB DIAG > SPB Inputs
HDBOB
From OFF position of switch used to bypass hoistway doors. Used for monitoring switch.
Hoistway Door Bypass OFF B @ SPB DIAG > SPB Inputs
ICEN In Car Inspection Enable @ System IO > System Inputs
ICPD In Car Inspection push button down @ System IO > System Inputs
ICPU In Car Inspection push button up @ System IO > System Inputs
ICTD Inspection Cartop down button @ System IO > System Inputs
ICTU Inspection Cartop up button @ System IO > System Inputs
IN1H Programmable 24VDC active high input. Seismic (SS) or Counterweight (EQH) input.
IN2H Programmable 24VDC active high input. Seismic (SS) or Counterweight (EQH) input
INA Inspection, Access. Hoistway access enable switch input @ System IO > System Inputs
INAO Access enable input from Safety Processor A
INCP Inspection Car Panel @ System IO > System Inputs
INCPO Inspection Car Panel input from Safety Processor A
INCT Inspection, Cartop @ System IO > System Inputs
INCTD Inspection Cartop Down input
INCTO Inspection Cartop input from Safety Processor A
INCTU Inspection Cartop Up input
IND Independent service input, @ SYSTEM IO > PROGRAMMED INPUTS
IND SERV Independent Service
IP Internet Protocol
LLI Light Load Input. Input from load weigher @ System IO > Programmed Inputs
LOP Landing Operating Panel
LOPM Loss Of Power input to Safety Processor B from SCE-UPD board
LOT Lobby Open Dwell Time. Defined time for doors to remain @ SPA DIAG > Door Dwell Times
MAIN CLOCK Main Clock @ PLDDIAG > PLD Inputs
MBRE Monitor for low side solid state driver for brake contactor @ PLD > PLD Inputs
MDRE Monitor for Drive Enable (output from controller)
MC-CPI-2 The serial car panel interface board
MEB1 2 Monitor for low side solid state driver for EB1/2 to PLD
MEB3 4 Monitor of solid state driver for EB3/4 @ SPB DIAG > SPB Inputs Car stop bypass)
MLT Motor Limit Timer (anti-stall) @ ACTION INFO > Prohibit Run/Start Due to
MPME Monitor for PM solid state driver for Up Fast valve @ PLD DIAG > PLD Inputs
MPSBR Brake contactor output monitor @ SPA DIAG > SPA Inputs
MRDN Machine Room DOWN (inspection direction button) @ PLD DIAG > PLD Inputs
MREN Machine Room Enable (inspection enable button) @ PLD DIAG > PLD Inputs
Table 2.4 Acronym Descriptions and Memory Locations
Acronym Description and Memory Location
To Next Page
