Configuration and Troubleshooting
2-46 Manual # 42-02-2P26
J11 INCT Car top inspection/normal input
J27 SD MICRO Port for SD card event storage.
J13 IO1 - IO8 Programmable Input/Outputs. See job prints.
J14 ETHERNET Ethernet port. Web App configuration/per job use. See job prints.
J15 PLD JTAG MCE use only.
J16 SHLD CAN shield connection.
J16 CANL1 CAN connection 1, Low
J16 CANH1 CAN connection 1, High
J16 CANL2 CAN connection 2, Low
J16 CANH2 CAN connection 2, High
J17, MCE FLPC Fan/Light power control output
J17, MCE CTPR Cartop box power control output
J17, MCE LOPM 24V power monitor
J17, MCE 1 Common
J17, MCE 24VDC 24VDC
J18 CANL3 CAN connection 3, Low
J18 CANH3 CAN connection 3, High
J18 SHLD CAN shield connection.
J19, MCE PMP Primary motor contactor
J19, MCE BRP Brake contactor
J19, MCE CONFIG Door lock string configuration input.
J19, MCE 24VDC 24VDC output
J19, MCE TR_HY Traction/Hydro default determination.
J19, MCE 1 Common
J20 USB USB drive port
J21, MCE MCE TEST Do not use.
J22, MCE +24VINT 24V power for 12V source on Brake Board
J22, MCE GND Ground for 12V source on Brake Board
J22, MCE BRPK Brake pick control
J22, MCE BREDC Brake enable DC
J22, MCE BRFLT Brake fault
J22, MCE BROM Brake Contact Monitor
J23, MCE MCE TEST Do not use.
J24, MCE Serial Drive serial control
J25, MCE DCOM Drive Common
J25, MCE DRE Drive Enable
J25, MCE DPS- Drive power supply negative
J25, MCE DPS+ Drive power supply positive
J25, MCE DRDY Drive Ready input
J25, MCE DRDO Drive On input
J25, MCE DFLT Drive fault input
J25, MCE NC No connection
J26, MCE Serial Drive serial control
Table 2.9 CPU Connector Assignments
Connector Assignment Description
