Troubleshooting Reference
2-45
element
TM
Series
Table 2.9 CPU Connector Assignments
Connector Assignment Description
J3 RGOK Hydraulic: Thermal overload and/or oil tank temp shutdown input.
Traction: Rope Gripper OK (not set) input.
OK = 24V. Triggered = 0V.
J3 +24V +24V supply output for use with RGOK.
J3 L24V +24V supply output for use with counterweight derailment detection.
J3 1 Common
J3 FRA Main landing smoke/fire sensor input. Recall to alternate floor.
J3 FRS Smoke/fire sensor for all landings but the main landing. Recall to main floor.
J3 FRSA Fire Service Alternate initiating device, machine room input. Recall to alternate
floor.
J3 FRSM Fire Service Main initiating device. Recall to main floor.
J4 MCE TEST Do not use.
J5 ICEN/IN1 In car inspection enable / programmable input. See job prints. If the
CONFIG01, Building Setup in-car inspection option is set to Yes, this input may
only be used for in-car inspection Enable.
J5 ICPU/IN2 In car inspection UP input / programmable input. See job prints. If the
CONFIG01, Building Setup in-car inspection option is set to Yes, this input may
only be used for in-car inspection Up.
J5 ICPD/IN3 In car inspection DOWN input / programmable input. See job prints. If the
CONFIG01, Building Setup in-car inspection option is set to Yes, this input may
only be used for in-car inspection Down.
J5 IN4 Programmable input. See job prints.
J5 IN5 Programmable input. See job prints.
J5 IN6 Programmable input. See job prints.
J6 1 (pin 1) Common. Serial fixtures to CAR.
J6 +24 (pin 2) 24V. Serial fixtures to CAR.
J6 CDATA (pin 3) Data. Serial fixtures to CAR.
J6 1 (pin4) Common. Serial fixtures to HALL.
J6 +24V (pin 5) 24V. Serial fixtures to HALL.
J6 HDATA (pin 6) Data. Serial fixtures to HALL.
J7 CAN, modular See job prints. May be used with MC-CPI-2 board for extra I/O in cabinet.
J8 CAN, modular See job prints.
J9 SHLD Shield connection, landing system/hoistway encoder
J9 B- Quadrature B-, hoistway encoder
J9 B+ Quadrature B+, hoistway encoder
J9 A-/SPD1 Quadrature A- (encoder) or SPD1 from LS-EDGE-EL
J9 A+/SPD0 Quadrature A+ (encoder) or SPD0 from LS-EDGE-EL
J9 DZ Door Zone, input
J10 INA Access Enable
J10 ATU Top Access, UP direction input
J10 ATD Top Access, DOWN direction input and down access limit
J10 ABU Bottom Access, UP direction input and up access limit
J10 ABD Bottom Access, DOWN direction input
J11 CTEN Car top inspection enable input
J11 INCP In car inspection/normal input
J11 ICTU Car top inspection UP button input
J11 ICTD Car top inspection DOWN button input
