Screen Descriptions
2-15
element
TM
Series
Recall
Switches
Element provides four car recall inputs, Recall S1 - S4.
- Latch Switch (Seconds): At the recall floor, the car will wait for this period
of time for an initiating action to be taken (i.e., independent control initi-
ated, access operation initiated, etc.) before automatically returning to nor-
mal passenger service.
- Recall Floor: Set to desired recall floor.
- Override Security (Yes/No): If Yes, the recall operation will override secu-
rity settings for the floor.
- Car Calls Disposition: How should registered car calls be handled before
the car recalls? (Cancel Calls/Answer Calls/Allow New Calls/Cancel Calls at
Next Stop)
- Door Operation (Cycle Doors/Doors Closed/Doors Open): Determines door
action upon arrival at the recall floor.
- Override Independent (Yes/No): If Yes, recall operation will override
Independent service.
Network
Settings
- IP Address: IP address of car on LAN.
- Subnet Mask: Subnet mask of car on LAN.
- Default Gateway: Default gateway of car on LAN.
- MAC Address
File Transfer
Menu
Allows parameters to be restored:
- Backup Current Settings (to SD)
- Restore Backup Settings (from SD)
- Restore Factory Settings (from SD)
When an option is selected, you are prompted to press OK to continue or
EXIT to abort without changing defaults.
Allows parameters to be transferred:
- Export Events to USB Drive
- Export Current Settings to USB Drive
- Import & Apply Settings from USB Drive
Register Calls On-board Car and Hall call registration controls.
Construct and
Bypass Faults
- Construction/Fault Bypass: When active, enables Construction opera-
tion, bypasses faults. Also requires that the Fault Bypass jumper on the
SCE-CPU board be set to BYPASS and the car be placed on Inspection
mode.
- Inspection Fault Bypass: When active, bypasses faults on Inspection
operation. Also requires that the Fault Bypass jumper on the SCE-CPU
board be set to BYPASS.
- Automatic Fault Bypass: Bypasses faults on Passenger operation. Also
requires that the Fault Bypass jumper on the SCE-CPU board be set to
BYPASS. A countdown timer will appear on the Home screen, counting
down from 2 hours. When the timer expires, the car will automatically exit
fault bypass operation. If more time is required, must be re-enabled.
Safety Tests Commissioning test assistance, Automated Tests on page 1-64.
Date and Time Date, time and day of the week setting controls.
Landing Sys-
tem Utilities
- Hoistway Learn (Landing System Learn) - Allows you to learn the hoist-
way, page 1-52.
- Landing System View - Displays position and speed information at upper
and lower leveling markers during floor leveling. Displays on/off status for
SDU (Step Down Up), ULM (Up Level Marker), DZ (Door Zone), DLM (Down
Level Marker), SDD (Step Down Down).
- Terminal Switch Learn: Hoistway switch position, speed, and delta learn
operation, page 1-57
Table 2.1 Touchscreen Organization and Content
Tab Subtab Description
