Chapter 5
| SNMP Commands
SNMP Target Host Commands
– 142 –
Command Mode
Global Configuration
Command Usage
â—† If you do not enter an snmp-server enable traps command, no notifications
controlled by this command are sent. In order to configure this device to send
SNMP notifications, you must enter at least one snmp-server enable traps
command. If you enter the command with no keywords, both authentication
and link-up-down notifications are enabled. If you enter the command with a
keyword, only the notification type related to that keyword is enabled.
â—† The snmp-server enable traps command is used in conjunction with the
snmp-server host command. Use the snmp-server host command to specify
which host or hosts receive SNMP notifications. In order to send notifications,
you must configure at least one snmp-server host command.
â—† The authentication, link-up, and link-down traps are legacy notifications, and
therefore when used for SNMP Version 3 hosts, they must be enabled in
conjunction with the corresponding entries in the Notify View assigned by the
snmp-server group command.
Example
Console(config)#snmp-server enable traps link-up-down
Console(config)#
Related Commands
snmp-server host (142)
snmp-server host This command specifies the recipient of a Simple Network Management Protocol
notification operation. Use the no form to remove the specified host.
Syntax
snmp-server host host-addr [inform [retry retries | timeout seconds]]
community-string
[version {1 | 2c | 3 {auth | noauth | priv} [udp-port port]}
no snmp-server host host-addr
host-addr - Internet address of the host (the targeted recipient).
(Maximum host addresses: 5 trap destination IP address entries)
inform - Notifications are sent as inform messages. Note that this option is
only available for version 2c and 3 hosts. (Default: traps are used)
retries - The maximum number of times to resend an inform message if
the recipient does not acknowledge receipt. (Range: 0-255; Default: 3)
seconds - The number of seconds to wait for an acknowledgment
before resending an inform message. (Range: 0-2147483647
centiseconds; Default: 1500 centiseconds)
