Chapter 11
| Link Aggregation Commands
Dynamic Configuration Commands
– 315 –
Example
The following example creates trunk 1 and then adds port 11:
Console(config)#interface port-channel 1
Console(config-if)#exit
Console(config)#interface ethernet 1/11
Console(config-if)#channel-group 1
Console(config-if)#
Dynamic Configuration Commands
lacp This command enables 802.3ad Link Aggregation Control Protocol (LACP) for the
current interface. Use the no form to disable it.
Syntax
[no] lacp
Default Setting
Disabled
Command Mode
Interface Configuration (Ethernet)
Command Usage
â—† The ports on both ends of an LACP trunk must be configured for full duplex,
either by forced mode or auto-negotiation.
â—† A trunk formed with another switch using LACP will automatically be assigned
the next available port-channel ID.
â—† If the target switch has also enabled LACP on the connected ports, the trunk
will be activated automatically.
â—† If more than eight ports attached to the same target switch have LACP enabled,
the additional ports will be placed in standby mode, and will only be enabled if
one of the active links fails.
Example
The following shows LACP enabled on ports 10-12. Because LACP has also been
enabled on the ports at the other end of the links, the show interfaces status port-
channel 1 command shows that Trunk1 has been established.
Console(config)#interface ethernet 1/10
Console(config-if)#lacp
Console(config-if)#interface ethernet 1/11
Console(config-if)#lacp
Console(config-if)#interface ethernet 1/12
Console(config-if)#lacp
Console(config-if)#end
