Chapter 8
| General
Security Measures
Port-based Traf
fic Segment
ation
– 267
–
show
traffic-segmentation
This
comm
and displa
ys the co
nfigu
red traffi
c
seg
m
ent
s.
Command Mode
Privi
leged Exec
Example
Console#show traffic-segmentation
Private VLAN status: Disabled
Up-link Port:
Ethernet 1/12
Down-link Port:
Ethernet 1/5
Ethernet 1/6
Ethernet 1/7
Ethernet 1/8
Console#
