Page #424 background imageLoading...
Page #424 background image
Chapter 17
| VLAN Commands
Configuring Voice VLANs
– 424 –
switchport voice vlan This command specifies the Voice VLAN mode for ports. Use the no form to disable
the Voice VLAN feature on the port.
Syntax
switchport voice vlan {manual | auto}
no switchport voice vlan
manual - The Voice VLAN feature is enabled on the port, but the port must
be manually added to the Voice VLAN.
auto - The port will be added as a tagged member to the Voice VLAN when
VoIP traffic is detected on the port.
Default Setting
Disabled
Command Mode
Interface Configuration
Command Usage
â—† When auto is selected, you must select the method to use for detecting VoIP
traffic, either OUI or 802.1ab (LLDP) using the switchport voice vlan rule
command. When OUI is selected, be sure to configure the MAC address ranges
in the Telephony OUI list using the voice vlan mac-address command.
â—† All ports are set to VLAN hybrid mode by default. Prior to enabling VoIP for a
port (by setting the VoIP mode to Auto or Manual as described below), ensure
that VLAN membership is not set to access mode using the switchport mode
command.
Example
The following example sets port 1 to Voice VLAN auto mode.
Console(config)#interface ethernet 1/1
Console(config-if)#switchport voice vlan auto
Console(config-if)#
switchport voice vlan
priority
This command specifies a CoS priority for VoIP traffic on a port. Use the no form to
restore the default priority on a port.
Syntax
switchport voice vlan priority priority-value
no switchport voice vlan priority
priority-value - The CoS priority value. (Range: 0-6)
