Chapter 19
| Quality of Service Commands
– 444
match This command defines the criteria used to classify traffic. Use the no form to delete
the matching criteria.
Syntax
[no] match {access-list acl-name | ip dscp dscp |
ip precedence ip-precedence | vlan vlan-id}
acl-name - Name of the access control list. Any type of ACL can be specified,
including standard or extended IP ACLs and MAC ACLs.
(Range: 1-16 characters)
dscp - A Differentiated Service Code Point value. (Range: 0-63)
ip-precedence - An IP Precedence value. (Range: 0-7)
vlan-id - A VLAN. (Range:1-4093)
Default Setting
None
Command Mode
Class Map Configuration
Command Usage
First enter the class-map command to designate a class map and enter the
Class Map configuration mode. Then use match commands to specify the fields
within ingress packets that must match to qualify for this class map.
If an ingress packet matches an ACL specified by this command, any deny rules
included in the ACL will be ignored.
If match criteria includes an IP ACL or IP priority rule, then a VLAN rule cannot
be included in the same class map.
If match criteria includes a MAC ACL or VLAN rule, then neither an IP ACL nor IP
priority rule can be included in the same class map.
Up to 16 match entries can be included in a class map.
Example
This example creates a class map called “rd-class#1,” and sets it to match packets
marked for DSCP service value 3.
Console(config)#class-map rd-class#1 match-any
Console(config-cmap)#match ip dscp 3
Console(config-cmap)#
