Chapter 9
| Access Control Lists
IPv4 ACLs
– 276
–
Command Mode
Privi
leged Exec
Example
Console#show ip access-list standard
IP standard access-list david:
permit host 10.1.1.21
permit 168.92.0.0 255.255.15.0
Console#
Related Commands
permit, deny
, redir
ec
t-to (271)
ip access-group (274)
275
277
