Rev. 01/2015 117
Note the assignment of the ignition outputs at the output connector
Note that the ignition outputs at the output connector of the individual
device types are not always assigned to a pin or a pole with the same letter.
The assignment of the ignition outputs to the pins or poles of the output
connector can be found in chapter Input and Output Wiring on the Controller
on page 28.
Misfire Detection
Which of the displayed outputs can actually be fired, depends on the set
sequence number (see Set Sequence Number on page 80). The sequence of
the ignition depends on the wiring of the ignition controller outputs with
the ignition coils.
The following assessments can be run for the purpose of localizing errors:
– An oscilloscope at the measuring output of the ignition controller is used to measure the
low-voltage-side output voltage and wave form.
– The output harness and the state of the ignition circuits can be evaluated by measuring
the respective voltage at the output clamps.
– With the aid of a timing light, all high tension leads can be tapped. A consistent flash
frequency indicates proper function.
5. To finish the self test, you have the following options:
– Computer: Press [Shift]+[S] or [Esc]
– Hand-held programmer: Press [S] or [ESC]
10.3.5 Customer Service Information
You can reach our customer service during business hours at the following phone and fax
number, or by e-mail:
Phone: +49 5141 93 99 0
Fax: +49 5141 93 99 99
Email: service@motortech.de
10.3.6 Returning Equipment for Repair / Inspection
To return the device for repair and inspection, obtain a return form and return number from
MOTORTECH.
Fill out the return form completely. The completely filled out return form guarantees fast,
uncomplicated processing of your repair order.
