26 Rev. 01/2015
5.1 Unpacking
Unpack the device, taking care not to damage it, and ensure that the operating manual is always
stored with the ignition controller and is easily accessible. Check the contents for completeness
and verify that the device type meets your application requirements.
Scope of Supply
The scope of supply of the MIC500 ignition controllers consists of the following components:
– Ignition controller MIC500
– Installation set incl. four vibration dampers
– Ground strap
– Storage device (USB flash drive or CD-ROM) with software for configuring the ignition
controller
– RS232 interface cable for connecting the ignition controller with a PC/laptop or hand-held
programmer
– Operating manual
5.2 Determine the Installation Location of the Pickup and the Trigger Disc
Depending on engine type and application, the position of the pickup must be specified. All
angle reference information is based on:
TDC 1st cylinder / Compression cycle
The installation location for the pickup must have adequate mechanical strength and must not
exceed the specified temperature ranges. The pickup is designed for its appropriate use only,
multiple use of the pickup signal is not permissible. The N+1 triggering can be carried out via the
crankshaft or the camshaft. Ensure good accessibility to facilitate the calibration of the pickup.
Comply with the pertinent regulations for the wire routing.
The precise position of the pickup is shown in the example in chapter Input Wiring – Pickup on
page 54.
INSTALLATION INSTRUCTIONS
